Dietz 210HP SERIES

Dietz 210HP SERIES Specifications

• Mechanical

  Set Point Ranges
  30–5000 psi (2.1-345 bar)

  Repeatability
  ± 2% FS

  Maximum Overpressure
  9000 psi (620 bar)

  Mechanical Capability
  High pressure switch

  Mechanical Life
  1,000,000 Cycles


  Temperature Range
  -20–180°F (-29-82°C)

• Physical

  Housing Material
  Zinc Plated Steel, Optional: Stainless Steel—may extend delivery time

  Diaphragm
  Nitrile (other options available on request)

  Pressure Port
  ¼" NPT Male

  Environmental Protection
  IP 65

  Electrical Connection
  Din 43650 A

  Weight
  0.37 lbs (0.17 kg)

• Electrical

  Switch Type
  SPDT Snap Action

  Current Rating
  5 A 12/24 VDC – 125 VAC
  3 A 250 VAC
  Optional: 10 A or Gold Contacts—may extend delivery time
