VEP 654 SERIES

VEP 654 SERIES Specifications

• Mechanical

  Standard Tolerance
  ±10%

  Switch Type
  SPDT (single pole / double throw) or DPDT (double pole / double throw)

  Switching Medium
  Air or compatible fluids

  Mechanical Capability
  Low Pressure switch, vacuum switch, differential switch

  Mechanical Life
  100,000 cycles

  Set-Point Ranges
  0.03 to 6 PSI  (2.07–414 mbar)

  Proof Pressure
  75 PSI (5.2 bar)

  Hysteresis
  10% to 50% of set point

  Operating Temp.
  -65°F to 350°F (-54–177°C)

• Physical

  Case Material
  Aluminum, Gold Anodized

  Seal
  Varies by option - See Detailed Specs sheet

  Diaphragm
  Mylar

  Pressure Port
  Varies by option - See Detailed Specs sheet

  Electrical Connections
  Wire leads or Mate n lok 1-480701

  Weight
  Less than 6 ounces

• Electrical

  Current Rating
  Resistive 5 AMP

  Operating Voltage
  30VDC
